Roadway Width 4.2m Steel Deck Bridge Delta Bridge

Roadway Width 4.2m Steel Deck Bridge Delta Bridge
Roadway Width 4.2m Steel Deck Bridge Delta Bridge

Large Image :  Roadway Width 4.2m Steel Deck Bridge Delta Bridge

Product Details:
Place of Origin: Hubei,China
Brand Name: China Harzone
Certification: ISO9001:2015
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Supply Ability: 50000 Ton/Tons per Year
Detailed Product Description
Standard: AiSi, ASTM, BS, GB Grade: Q345B-Q460C
Place Of Origin: Hubei,China Brand Name: China Harzone
Type: Heavy Application: Steel Structure Bridge
Tolerance: ±1% Processing Service: Bending, Welding, Decoiling, Cutting, Punching
Certificate: ISO9001:2015 Color: Customers' Requirement
Structure Type: Steel Bridge Installation: Engineers Guidance
High Light:

4.2m Steel Deck Bridge

,

Delta Steel Deck Bridge

,

4.2m Delta Bridge

Roadway Width 4.2m Steel Deck Bridge Delta Bridge

Roadway Width 4.2m Steel Deck Bridge Delta Bridge​ Product performance

Roadway Width 4.2m Steel Deck Bridge Delta Bridge truss is 4.5 meters high and the unit section is 2.25 meters long. It can be used as a permanent bridge for concrete decks or as a semi-permanent bridge for steel decks.

Roadway Width 4.2m Steel Deck Bridge Delta Bridge a temporary or semi-permanent large-span assembled highway steel bridge, which can be erected with a span of 36 ~ 81 meters.



Roadway Width 4.2m Steel Deck Bridge Delta Bridge Product composition

Roadway Width 4.2m Steel Deck Bridge Delta Bridge is a through down bridge composed of upper chords, lower chords, triangular webs, beams, bridge panels and connectors. The connection between components is bolted. External or built sidewalks can be designed on both sides of the bridge.



Roadway Width 4.2m Steel Deck Bridge Delta Bridge​ Main technical data


Signle Span 36-81m,Extended by 2.225m Each Section
Designed Load HS20-44,HA,HB Highway Grade1,tacked Load 60t
Truss Height 4.5m
Bridge Deck Steel or COncrete
Roadway Width(single lane) 4.2m
Roadway Width(Double lane) 7.35m(can meet different requirements)
Sidewalk Width 1m/1.2m/1.5m




Roadway Width 4.2m Steel Deck Bridge Delta Bridge 0

Roadway Width 4.2m Steel Deck Bridge Delta Bridge 1

FAQ

1,How about quality control of your company?

Manufacturing process for steel bailey bridge in China,who has engaging in this line for over 50 years with an International Quality System Certification of ISO 9001:2015 and as cooperation partner with the research institutions of the People’s Liberation Army. And our products have been exported to more than 40 countries and regions in Asia,Africa,Latin America and Oceania.



2,Are you a factory or a trade company?

We are a factory with 8 production lines and various machines to fabricate steel bridge parts,pontoon bridges,mechanized bridges and other products.Also, we have get the exporting license to devote ourselves into global market.



3,Where is your loading port?

Shanghai Port,Nanjing Port,Tianjin Port.



Our Service

1,For all your inquires about us or our products,we will reply you in details within 24 hours.



2,We own professional sales&after-sales services who can speak fluent English language.



3,Tail-made Welcome to submit your idea, we can turn your idea to products.



4,Discounts are offered based on order quantities.





Harzone Industry was built in 1967, one of the subsidiary units of China State Shipbuilding Corporation Limited(CSSC), a state-owned and protected military company. Over the past four decades, the leaders of both the Party and nation have been caring for the growth of the company. Chairman Mao underlined the documents for the factory establishment. Later, ZhangAiping., one General, and Chen Shiju, one commander, inscribed name for the company. In 2008, Mr. He Guoqiang, Standing Committee of Political Bureau of CPC Central Committee, Secrrtary of the Discipline Inspection Commission of CPC Central Committee had paid a visit to the company and inspected the workshop and saw the erection of the mechanized bridge, who also encouraged the company to develope well.
Righe now, the company has one research center in Wuhan, which is the national degree, one trading center in Beijing, one manufactuing center in Chibi, three offices in Gana, Ethiopia and Peru.
Harzone Industry has enjoyed a proud history, it must also create a bridge future.
