| Name: | CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge | Brand Name: | China Harzone |
|---|---|---|---|
| Material: | Steel Bridge | Width: | 3.7m |
| Length: | 35-87.6m | Load: | HS20-44 |
| High Light: | prefabricated bailey suspension bridge,cb250 steel bailey suspension bridge,length 25m bailey truss bridge |
||
CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge(also is named compact panel bridge or PSB) are manufactured by China Harzone Industry Corp., Ltd. 60ft bridge are Single-single construction, and the 90ft bridge are Double-Single Reinforced 2 (DSR2) construction according to the request made by the owner. We provide the all the components except the launching tools.
Panel of CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge
The panels of CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge are monolithic unit welded in the factory and assembled by panel pin on the construction site, and the main structures are assembled according with the request of span and loading.
End system of CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge
The bridge end of CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge is composed of post end male, post end female, tie beam, bearing and bearing plate.
Launching equipment and tools of CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge
The launching equipment and tools of CB250 Steel Bridge Length 25-87.6m Bailey Suspension Bridge are made up of nose, roller, rock roller, joint, bolt and various spanners. The max loading of roller is 25t and the rock roller id 6t. The nose is netlike structure assembled by bridge components (not offered in this project).
The mechanical properties of Q345B
| Yield point,σs MPa |
Tensile strength σb MPa |
Extend rate δs, |
Work of concussion,Akv, (vertical), J |
180obending test d= dia. a= thickness(dia.) |
|||||||||
| thickness(dia.,side length),mm | +20℃ | 0℃ | -20℃ | -40℃ | |||||||||
| ≤16 | ＞16~35 | ＞35~50 | ＞50~100 | Not less than | thickness(dia., mm) | ||||||||
| Not less than | ≤15 | ＞16~100 | |||||||||||
| 345 | 325 | 295 | 275 | 470~630 | 21 | 34 | d=2a | d=3a | |||||
